Revolutionary Building Technology
Developed in Sweden in the 1920s and perfected over decades, AAC combines concrete’s strength with insulation properties that surpass traditional materials.
Used extensively across Europe, Asia, and the Middle East, AAC is transforming construction worldwide.
AAC Material Science
The Formula
65%
Silica Sand
Structural matrix
10-15%
Cement
Binding agent
15-20%
Lime
Autoclaving catalyst
5-10%
Fly Ash
Recycled content
0.05%
Aluminum Powder
Creates cells
Result: 70-80% air-filled cellular structure
Key Properties Created
R-30 insulation value
Superior thermal resistance
1/4 weight of concrete
Lightweight construction
60-65 dB sound reduction
Excellent acoustics
2,192°F fire resistance
Non-combustible material
How AAC Is Manufactured
Mixing
Raw materials combined with water
Expansion
Aluminum creates hydrogen gas bubbles
Cutting
Wire-cut to precise dimensions (±1mm)
Autoclaving
12 hours at 374°F and 12 bar pressure
Result: Tobermorite crystal formation for strength
AAC Technical Properties
| Property | Specification | Advantage |
|---|---|---|
| Density | 25–50 lb/ft³ | 75% lighter |
| Compressive Strength | 500–700 psi | Exceeds codes |
| Thermal Conductivity | 0.09–0.14 W/mK | 10x better insulation |
| Fire Rating | 4–6 hours | 3x code requirement |
| Sound Reduction | 60–65 dB | 2x wood frame |
Energy Efficiency Technology
The AAC Thermal Effect
Insulation
High R-value slows heat transfer
Thermal Mass
Stores and releases heat gradually
Result
70% reduction in temperature swings
Dynamic Performance
Effective R-40+ in real conditions
MOTIVA's Advanced AAC System
Suspended Slab Innovation
- 8-inch AAC blocks
- 2-inch concrete joists
- Steel mesh reinforcement
- 11-inch total thickness
- Superior load distribution
Waterproofing Technology
- Polymerized sealers
- TPO/standing seam options
- 50+ year warranty capability
Fire Protection Science
Why AAC Doesn't Burn
Zero organic content
No combustible materials
Tobermorite crystals stable to 2,192°F
Extreme heat resistance
No toxic smoke
Safe during fire events
No spalling or explosion
Maintains structural integrity
Fire Ratings
4"
wall: 4 hours
6"
wall: 6 hours
8"
wall: 8 hours
Next-Generation AAC Technology
Nano-enhanced AAC
30% stronger
3D printing
applications
Carbon-negative
formulations
Ultra-light variants
15 lb/ft³
